Product Ref.
Internal Dia. Inches
Internal Dia. mm
External Dia mm
Wall Thickness Overall mm
Weight kg/m
Min Bend Radius
Vacuum m of H2O
Working Pressure Bar
Coil Length Metres
Quantity
Product Ref.WFB04
Internal Dia. Inches⅜"
Internal Dia. mm10
External Dia mm19.0
Wall Thickness Overall mm4.5
Weight kg/m0.4
Min Bend Radius25
Vacuum m of H2O9
Working Pressure Bar25.5
Coil Length Metres30 / 50
Product Ref.WFB05
Internal Dia. Inches½”
Internal Dia. mm13
External Dia mm22.0
Wall Thickness Overall mm4.5
Weight kg/m0.5
Min Bend Radius30
Vacuum m of H2O9
Working Pressure Bar25.5
Coil Length Metres30 / 50
Product Ref.WFB06
Internal Dia. Inches⅝”
Internal Dia. mm16
External Dia mm25.0
Wall Thickness Overall mm4.5
Weight kg/m0.6
Min Bend Radius35
Vacuum m of H2O9
Working Pressure Bar21.5
Coil Length Metres30 / 50
Product Ref.WFB07
Internal Dia. Inches¾”
Internal Dia. mm19
External Dia mm28.0
Wall Thickness Overall mm4.5
Weight kg/m0.7
Min Bend Radius40
Vacuum m of H2O9
Working Pressure Bar17.0
Coil Length Metres30 / 50
Product Ref.WFB10
Internal Dia. Inches1”
Internal Dia. mm25
External Dia mm36.9
Wall Thickness Overall mm6.0
Weight kg/m1.2
Min Bend Radius60
Vacuum m of H2O9
Working Pressure Bar15.5
Coil Length Metres30 / 50
Product Ref.WFB12
Internal Dia. Inches1¼”
Internal Dia. mm32
External Dia mm43.0
Wall Thickness Overall mm5.5
Weight kg/m1.4
Min Bend Radius80
Vacuum m of H2O9
Working Pressure Bar13.5
Coil Length Metres30 / 50
Product Ref.WFBM35
Internal Dia. InchesMetric
Internal Dia. mm35
External Dia mm46.8
Wall Thickness Overall mm5.9
Weight kg/m1.6
Min Bend Radius95
Vacuum m of H2O9
Working Pressure Bar12.0
Coil Length Metres30 / 50
Product Ref.WFB15
Internal Dia. Inches1½”
Internal Dia. mm38
External Dia mm50.0
Wall Thickness Overall mm6.0
Weight kg/m1.8
Min Bend Radius100
Vacuum m of H2O9
Working Pressure Bar12.0
Coil Length Metres30 / 50
Product Ref.WFBM45
Internal Dia. InchesMetric
Internal Dia. mm45
External Dia mm58.0
Wall Thickness Overall mm6.5
Weight kg/m2.4
Min Bend Radius120
Vacuum m of H2O9
Working Pressure Bar10.0
Coil Length Metres30 / 50
Product Ref.WFB20
Internal Dia. Inches2”
Internal Dia. mm51
External Dia mm65.0
Wall Thickness Overall mm7.0
Weight kg/m2.8
Min Bend Radius130
Vacuum m of H2O9
Working Pressure Bar10.0
Coil Length Metres30 / 50
Product Ref.WFBM60
Internal Dia. InchesMetric
Internal Dia. mm60
External Dia mm74.2
Wall Thickness Overall mm7.1
Weight kg/m3.6
Min Bend Radius200
Vacuum m of H2O9
Working Pressure Bar8.0
Coil Length Metres30 / 50
Product Ref.WFB25
Internal Dia. Inches 2 ½"
Internal Dia. mm63
External Dia mm77.2
Wall Thickness Overall mm7.1
Weight kg/m3.7
Min Bend Radius210
Vacuum m of H2O9
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.WFB30
Internal Dia. Inches3"
Internal Dia. mm76
External Dia mm92.8
Wall Thickness Overall mm8.4
Weight kg/m5.0
Min Bend Radius250
Vacuum m of H2O9
Working Pressure Bar6.5
Coil Length Metres30 / 50
Product Ref.WFBM80
Internal Dia. InchesMetric
Internal Dia. mm80
External Dia mm96.0
Wall Thickness Overall mm8.0
Weight kg/m5.2
Min Bend Radius300
Vacuum m of H2O9
Working Pressure Bar4.5
Coil Length Metres30 / 50
Product Ref.WFB35
Internal Dia. Inches 3 ½"
Internal Dia. mm90
External Dia mm106.4
Wall Thickness Overall mm8.2
Weight kg/m6.0
Min Bend Radius350
Vacuum m of H2O9
Working Pressure Bar4.5
Coil Length Metres30
Product Ref.WFB40
Internal Dia. Inches4"
Internal Dia. mm102
External Dia mm122.0
Wall Thickness Overall mm10.0
Weight kg/m8.0
Min Bend Radius400
Vacuum m of H2O9
Working Pressure Bar4.0
Coil Length Metres30
Product Ref.WFB50
Internal Dia. Inches5"
Internal Dia. mm127
External Dia mm147.2
Wall Thickness Overall mm10.1
Weight kg/m10.0
Min Bend Radius500
Vacuum m of H2O9
Working Pressure Bar2.5
Coil Length Metres20
Product Ref.WFB60
Internal Dia. Inches6"
Internal Dia. mm152
External Dia mm175.0
Wall Thickness Overall mm11.5
Weight kg/m14.0
Min Bend Radius600
Vacuum m of H2O9
Working Pressure Bar2.0
Coil Length Metres20
(i) Maximum working pressure is based on a factor of safety of 3:1 on short term burst pressure at 20°C. If the temperature increases, please refer to the temperature pressure charts.
(ii) Lengths detailed above are as standard, however variations may be available subject to minimum order quantities. Weights are approximate dependent upon working tolerance and
density of materials.
(iii) Bending diameter information is intended as a guide to the minimum bend radius at 20°C ambient temperature without restricting the bore. It does not mean that the hose cannot be
bent below the given dimensions but restriction is likely to occur.
