Product Ref.
Internal Dia. Inches
Internal Dia. mm
External Dia mm
Wall Thickness Overall mm
Weight kg/m
Min Bend Radius
Vacuum m of H2O
Working Pressure Bar
Coil Length Metres
Quantity
Product Ref.SFXE04
Internal Dia. Inches⅜"
Internal Dia. mm10
External Dia mm16.2
Wall Thickness Overall mm3.1
Weight kg/m0.18
Min Bend Radius20
Vacuum m of H2O9.5
Working Pressure Bar10.0
Coil Length Metres30 / 50
Product Ref.SFXE05
Internal Dia. Inches½”
Internal Dia. mm13
External Dia mm19.2
Wall Thickness Overall mm3.1
Weight kg/m0.21
Min Bend Radius20
Vacuum m of H2O9.5
Working Pressure Bar10.0
Coil Length Metres30 / 50
Product Ref.SFXE06
Internal Dia. Inches⅝”
Internal Dia. mm16
External Dia mm22.2
Wall Thickness Overall mm3.1
Weight kg/m0.28
Min Bend Radius25
Vacuum m of H2O9.5
Working Pressure Bar9.0
Coil Length Metres30 / 50
Product Ref.SFXE07
Internal Dia. Inches¾”
Internal Dia. mm19
External Dia mm26.0
Wall Thickness Overall mm3.5
Weight kg/m0.32
Min Bend Radius35
Vacuum m of H2O9.5
Working Pressure Bar7.5
Coil Length Metres30 / 50
Product Ref.SFXEM20
Internal Dia. InchesMetric
Internal Dia. mm20
External Dia mm27.0
Wall Thickness Overall mm3.5
Weight kg/m0.34
Min Bend Radius35
Vacuum m of H2O9.5
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.SFXE10
Internal Dia. Inches1”
Internal Dia. mm25
External Dia mm33.0
Wall Thickness Overall mm4.0
Weight kg/m0.52
Min Bend Radius40
Vacuum m of H2O9.5
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.SFXE12
Internal Dia. Inches1¼”
Internal Dia. mm32
External Dia mm40.2
Wall Thickness Overall mm4.1
Weight kg/m0.66
Min Bend Radius65
Vacuum m of H2O9.5
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.SFXEM35
Internal Dia. InchesMetric
Internal Dia. mm35
External Dia mm43.6
Wall Thickness Overall mm4.3
Weight kg/m0.75
Min Bend Radius75
Vacuum m of H2O9.5
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.SFXE15
Internal Dia. Inches1½”
Internal Dia. mm38
External Dia mm47.0
Wall Thickness Overall mm4.5
Weight kg/m0.80
Min Bend Radius75
Vacuum m of H2O9.5
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.SFXEM45
Internal Dia. InchesMetric
Internal Dia. mm45
External Dia mm55.0
Wall Thickness Overall mm5.0
Weight kg/m1.15
Min Bend Radius90
Vacuum m of H2O9.5
Working Pressure Bar7.0
Coil Length Metres30 / 50
Product Ref.SFXE20
Internal Dia. Inches2”
Internal Dia. mm51
External Dia mm61.8
Wall Thickness Overall mm5.4
Weight kg/m1.30
Min Bend Radius100
Vacuum m of H2O9.5
Working Pressure Bar6.0
Coil Length Metres30 / 50
Product Ref.SFXEM60
Internal Dia. InchesMetric
Internal Dia. mm60
External Dia mm72.0
Wall Thickness Overall mm5.5
Weight kg/m1.75
Min Bend Radius120
Vacuum m of H2O9.0
Working Pressure Bar5.0
Coil Length Metres30 / 50
Product Ref.SFXE25
Internal Dia. Inches2½”
Internal Dia. mm63
External Dia mm74.0
Wall Thickness Overall mm5.5
Weight kg/m1.80
Min Bend Radius125
Vacuum m of H2O9.0
Working Pressure Bar4.5
Coil Length Metres30 / 50
Product Ref.SFXE30
Internal Dia. Inches3”
Internal Dia. mm76
External Dia mm89.6
Wall Thickness Overall mm6.8
Weight kg/m2.30
Min Bend Radius150
Vacuum m of H2O9.0
Working Pressure Bar4.0
Coil Length Metres30 / 50
Product Ref.SFXEM80
Internal Dia. InchesMetric
Internal Dia. mm80
External Dia mm92.6
Wall Thickness Overall mm6.3
Weight kg/m2.50
Min Bend Radius220
Vacuum m of H2O9.0
Working Pressure Bar3.0
Coil Length Metres30 / 50
Product Ref.SFXE35
Internal Dia. Inches3½”
Internal Dia. mm89
External Dia mm103.6
Wall Thickness Overall mm7.3
Weight kg/m3.00
Min Bend Radius260
Vacuum m of H2O9.0
Working Pressure Bar3.0
Coil Length Metres30
Product Ref.SFXE40
Internal Dia. Inches4”
Internal Dia. mm102
External Dia mm118.0
Wall Thickness Overall mm8.0
Weight kg/m3.70
Min Bend Radius300
Vacuum m of H2O9.0
Working Pressure Bar2.5
Coil Length Metres30
Product Ref.SFXE50
Internal Dia. Inches5”
Internal Dia. mm127
External Dia mm143.2
Wall Thickness Overall mm8.1
Weight kg/m4.70
Min Bend Radius350
Vacuum m of H2O9.0
Working Pressure Bar2.0
Coil Length Metres30
Product Ref.SFXE60
Internal Dia. Inches6”
Internal Dia. mm152
External Dia mm170.4
Wall Thickness Overall mm9.2
Weight kg/m6.90
Min Bend Radius450
Vacuum m of H2O9.0
Working Pressure Bar1.5
Coil Length Metres20
(i) Maximum working pressure is based on a factor of safety of 3:1 on short term burst pressure at 20°C. If the temperature increases, please refer to the temperature pressure charts.
(ii) Lengths detailed above are as standard, however variations may be available subject to minimum order quantities. Weights are approximate dependent upon working tolerance and density of materials.
(iii) Bending diameter information is intended as a guide to the minimum bend radius at 20°C ambient temperature without restricting the bore. It does not mean that the hose cannot be bent below the given dimensions but restriction is likely to occur.
