Product Ref.
Internal Dia. Inches
Internal Dia. mm
External Dia mm
Wall Thickness Overall mm
Weight kg/m
Min Bend Radius
Vacuum m of H2O
Working Pressure Bar
Coil Length Metres
Quantity
Product Ref.RFH19/26
Internal Dia. Inches¾”
Internal Dia. mm19
External Dia mm26.0
Wall Thickness Overall mm3.5
Weight kg/m0.38
Min Bend Radius130
Vacuum m of H2O-
Working Pressure Bar12
Coil Length Metres50
Product Ref.RFH25/34
Internal Dia. Inches1"
Internal Dia. mm25
External Dia mm34.0
Wall Thickness Overall mm4.5
Weight kg/m0.63
Min Bend Radius170
Vacuum m of H2O-
Working Pressure Bar12
Coil Length Metres50
(i) Maximum working pressure is based on a factor of safety of 3:1 on short term burst pressure at 20°C. If the temperature increases, please refer to the temperature pressure charts.
(ii) Lengths detailed above are as standard, however variations may be available subject to minimum order quantities. Weights are approximate dependent upon working tolerance and
density of materials.
(iii) Bending diameter information is intended as a guide to the minimum bend radius at 20°C ambient temperature without restricting the bore. It does not mean that the hose cannot be
bent below the given dimensions but restriction is likely to occur.
