Product Ref.
Internal Dia. Inches
Internal Dia. mm
External Dia mm
Wall Thickness Overall mm
Weight kg/m
Min Bend Radius
Vacuum m of H2O
Working Pressure Bar
Coil Length Metres
Quantity
Product Ref.FP3/6
Internal Dia. Inches4∕34"
Internal Dia. mm3.0
External Dia mm6.0
Wall Thickness Overall mm1.5
Weight kg/m0.02
Min Bend Radius12
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP5/8
Internal Dia. Inches⅕"
Internal Dia. mm5.0
External Dia mm8.0
Wall Thickness Overall mm1.5
Weight kg/m0.03
Min Bend Radius20
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP6/9
Internal Dia. Inches¼"
Internal Dia. mm6.0
External Dia mm9.0
Wall Thickness Overall mm1.5
Weight kg/m0.04
Min Bend Radius24
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP6/12
Internal Dia. Inches¼"
Internal Dia. mm6.0
External Dia mm12.0
Wall Thickness Overall mm3.0
Weight kg/m0.10
Min Bend Radius24
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP8/11
Internal Dia. Inches5∕16"
Internal Dia. mm8.0
External Dia mm11.0
Wall Thickness Overall mm1.5
Weight kg/m0.05
Min Bend Radius32
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP8/14
Internal Dia. Inches5∕16"
Internal Dia. mm8.0
External Dia mm14.0
Wall Thickness Overall mm3.0
Weight kg/m0.12
Min Bend Radius32
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP10/16
Internal Dia. Inches⅜"
Internal Dia. mm10.0
External Dia mm16.0
Wall Thickness Overall mm3.0
Weight kg/m0.14
Min Bend Radius40
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
Product Ref.FP12/15
Internal Dia. Inches½"
Internal Dia. mm12.0
External Dia mm15.0
Wall Thickness Overall mm1.5
Weight kg/m0.18
Min Bend Radius48
Vacuum m of H2O-
Working Pressure Bar-
Coil Length Metres30
(i) Maximum working pressure is based on a factor of safety of 3:1 on short term burst pressure at 20°C. If the temperature increases, please refer to the temperature pressure charts.
(ii) Lengths detailed above are as standard, however variations may be available subject to minimum order quantities. Weights are approximate dependent upon working tolerance and
density of materials.
(iii) Bending diameter information is intended as a guide to the minimum bend radius at 20°C ambient temperature without restricting the bore. It does not mean that the hose cannot be
bent below the given dimensions but restriction is likely to occur.
