Product Ref.
Internal Dia. Inches
Internal Dia. mm
External Dia mm
Wall Thickness Overall mm
Weight kg/m
Min Bend Radius
Vacuum m of H2O
Working Pressure Bar
Coil Length Metres
Quantity
Product Ref.CSOR10
Internal Dia. Inches1”
Internal Dia. mm25.4
External Dia mm34.4
Wall Thickness Overall mm4.5
Weight kg/m0.54
Min Bend Radius160
Vacuum m of H2O9
Working Pressure Bar13.3
Coil Length Metres30 / 50
Product Ref.CSORM28
Internal Dia. InchesMetric
Internal Dia. mm28
External Dia mm37.2
Wall Thickness Overall mm4.6
Weight kg/m0.62
Min Bend Radius180
Vacuum m of H2O9
Working Pressure Bar11.5
Coil Length Metres30 / 50
Product Ref.CSORM30
Internal Dia. InchesMetric
Internal Dia. mm30
External Dia mm39.2
Wall Thickness Overall mm4.6
Weight kg/m0.66
Min Bend Radius190
Vacuum m of H2O9
Working Pressure Bar10.1
Coil Length Metres30 / 50
Product Ref.CSOR12
Internal Dia. Inches1¼”
Internal Dia. mm32
External Dia mm41.2
Wall Thickness Overall mm4.6
Weight kg/m0.68
Min Bend Radius200
Vacuum m of H2O9
Working Pressure Bar10.0
Coil Length Metres30 / 50
Product Ref.CSORM35
Internal Dia. InchesMetric
Internal Dia. mm35
External Dia mm44.6
Wall Thickness Overall mm4.8
Weight kg/m0.78
Min Bend Radius220
Vacuum m of H2O9
Working Pressure Bar8.8
Coil Length Metres30 / 50
Product Ref.CSOR15
Internal Dia. Inches1½”
Internal Dia. mm38
External Dia mm48.2
Wall Thickness Overall mm5.1
Weight kg/m0.9
Min Bend Radius230
Vacuum m of H2O9
Working Pressure Bar8.7
Coil Length Metres30 / 50
Product Ref.CSORM40
Internal Dia. InchesMetric
Internal Dia. mm40
External Dia mm50.8
Wall Thickness Overall mm5.4
Weight kg/m0.98
Min Bend Radius260
Vacuum m of H2O9
Working Pressure Bar7.9
Coil Length Metres30 / 50
Product Ref.CSORM45
Internal Dia. InchesMetric
Internal Dia. mm45
External Dia mm55.8
Wall Thickness Overall mm5.4
Weight kg/m1.17
Min Bend Radius280
Vacuum m of H2O9
Working Pressure Bar7.5
Coil Length Metres30 / 50
Product Ref.CSOR20
Internal Dia. Inches2”
Internal Dia. mm51.6
External Dia mm62.8
Wall Thickness Overall mm5.6
Weight kg/m1.3
Min Bend Radius300
Vacuum m of H2O9
Working Pressure Bar7.3
Coil Length Metres30 / 50
Product Ref.CSORM60
Internal Dia. InchesMetric
Internal Dia. mm60
External Dia mm72.0
Wall Thickness Overall mm6.0
Weight kg/m1.47
Min Bend Radius380
Vacuum m of H2O9
Working Pressure Bar5.8
Coil Length Metres30 / 50
Product Ref.CSOR25
Internal Dia. Inches2½”
Internal Dia. mm63.5
External Dia mm75.7
Wall Thickness Overall mm6.1
Weight kg/m1.6
Min Bend Radius370
Vacuum m of H2O9
Working Pressure Bar6.0
Coil Length Metres30 / 50
Product Ref.CSOR30
Internal Dia. Inches3”
Internal Dia. mm76
External Dia mm89.2
Wall Thickness Overall mm6.6
Weight kg/m1.96
Min Bend Radius450
Vacuum m of H2O9
Working Pressure Bar5.7
Coil Length Metres30 / 50
Product Ref.CSORM80
Internal Dia. InchesMetric
Internal Dia. mm80
External Dia mm93.0
Wall Thickness Overall mm6.5
Weight kg/m2.23
Min Bend Radius530
Vacuum m of H2O9
Working Pressure Bar4.8
Coil Length Metres30 / 50
Product Ref.CSOR35
Internal Dia. Inches3½”
Internal Dia. mm90
External Dia mm104.0
Wall Thickness Overall mm7.0
Weight kg/m2.26
Min Bend Radius550
Vacuum m of H2O9
Working Pressure Bar5.0
Coil Length Metres30
Product Ref.CSOR40
Internal Dia. Inches4”
Internal Dia. mm102
External Dia mm118.0
Wall Thickness Overall mm8.0
Weight kg/m3.64
Min Bend Radius630
Vacuum m of H2O9
Working Pressure Bar4.3
Coil Length Metres30
Product Ref.CSOR50
Internal Dia. Inches5”
Internal Dia. mm127
External Dia mm144.2
Wall Thickness Overall mm8.6
Weight kg/m4.83
Min Bend Radius850
Vacuum m of H2O9
Working Pressure Bar4.0
Coil Length Metres30
Product Ref.CSORM140
Internal Dia. Inches5½”
Internal Dia. mm140
External Dia mm159.6
Wall Thickness Overall mm9.8
Weight kg/m6.06
Min Bend Radius1000
Vacuum m of H2O9
Working Pressure Bar3.7
Coil Length Metres30
Product Ref.CSOR60
Internal Dia. Inches6”
Internal Dia. mm152
External Dia mm172.4
Wall Thickness Overall mm10.2
Weight kg/m6.83
Min Bend Radius1100
Vacuum m of H2O9
Working Pressure Bar3.7
Coil Length Metres30
Product Ref.CSOR80
Internal Dia. Inches8”
Internal Dia. mm204
External Dia mm227.0
Wall Thickness Overall mm11.5
Weight kg/m10.3
Min Bend Radius2030
Vacuum m of H2O8
Working Pressure Bar3.3
Coil Length Metres10
Product Ref.CSOR100
Internal Dia. Inches10”
Internal Dia. mm254
External Dia mm282.0
Wall Thickness Overall mm14.0
Weight kg/m15.23
Min Bend Radius2540
Vacuum m of H2O8
Working Pressure Bar2.0
Coil Length Metres10
(i) Maximum working pressure is based on a factor of safety of 3:1 on short term burst pressure at 20°C. If the temperature increases, please refer to the temperature pressure charts.
(ii) Lengths detailed above are as standard, however variations may be available subject to minimum order quantities. Weights are approximate dependent upon working tolerance and
density of materials.
(iii) Bending diameter information is intended as a guide to the minimum bend radius at 20°C ambient temperature without restricting the bore. It does not mean that the hose cannot be
bent below the given dimensions but restriction is likely to occur.
