Hose & Ducting - Selection Guide 2024/25 www.griflex.com MANUFACTURED UK OWNED& REACh
Introduction With so many product options we are sure to have a solution for you and your application. If you require a size, length, or colour not shown please call our sales team. To keep up to date with the latest Griflex news and information visit our website www.griflex.com. • 100% UK owned and manufactured • Technical Specialists in Hose and ducting solutions • 5 new product ranges launched for 2024 with more coming soon • 74 different hose solutions • 55 spiral hoses • 16 braided hoses • 3 straight extrusions • Centrally located in Birmingham with products used in over 60 different Countries across 5 Continents • 2024 investment has doubled manufacturing capacity, to support continued growth. • Quality Assurance backed by ISO9001 certification and compliance to industry approvals. • Customer driven, including custom made product solutions • Excellent stock levels and quick manufacturing lead-times for project orders • Bespoke product solutions Griflex has been associated with the hose and ducting industry for over 60 years. As a British manufacturer, we are proud of our heritage, delivering high quality and technically advanced product solutions to both new and existing Customers. MANUFACTURED UK OWNED& 2
New Products… What’s New at Griflex… www.griflex.com GOING GREEN Investment in solar panels UV RESISTANT PACKAGING DOUBLED MANUFACTURING CAPACITY IN 2024 SFXEBOR Super Elastic, Braided Oil Resistant Hose AQHL Lightweight Ducting & Aquatic CUS Maximum strength, high vacuum hose ASHL 20 Bar Spray Hose • High volume delivery hoses • Extra compression strength helps to avoid crushing • Allows continuious use at high vacuum ratings • Minimal frictional loss is achieved by the smooth bore • Economy option • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance • 20 Bar working pressure • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore SFXE Super Elastic SpringFlex™ Increased size range, now including 12” diameter SPHXE Super Elastic Swimming Pool Hose Laser printing for medical and hygienic applications • Extra flexibility • Very high working pressures • Very good for vacuum • Two layers of food quality PVC • Exceptional kink and crush resistance from high tensile steel spiral • Extra flexibility • Smooth outer for easy cleaning • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Excellent chemical resistance 3 NEW NEW NEW NEW NEW NEW • SuperFlexible, tough and durable • Very high working pressures • Very good for vacuum • Exceptional kink and crush resistance from high tensile steel spiral
Application Guide System CD CDXE CDXT CDLXE CDFG CDAS ASDH ASDHXE ASDHXT SDS SDSXE SDSXT CUL CU CUXE CUXES CUXESZ CUXS CUAS CUS Page No. 8 8 8 8 9 9 9 9 101010101111111112121212 Temp Range oC Min -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -40 -10 -10 -10 Max +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 Size Range Inches Min 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2” 1/ 2”1” 1” 1” 1” 1” 1” 1” 2” Max 8” 4” 2” 2” 8” 8” 4” 4” 4” 4” 4” 4” 8” 10” 10” 10” 4” 10” 10” 6” mm Min 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 12.0 25.4 25.4 25.4 25.4 25.4 25.4 25.4 51.6 Max 203.0 102.0 51.6 51.6 203.0 203.0 102.0 102.0 102.0 102.0 102.0 102.0 254.0 254.0 254.0 254.0 102.0 254.0 254.0 152.0 Agriculture •••••••••••••••••••• Automotive • Construction • • • • • • • • • • • • Domestic Leisure & Marine • • • • Industrial •••••••••••••• Marine • • • • • Mining Rail Food Grade (EU2011) • • • • • • • Fire Retardant Anti Static • • Bend Radius mm (Based on 1”) 144 102 90 114 114 114 100 90 80 110 102 90 100 113 113 113 84 100 110 − Flexibility Rating (1-5) 34553344444433445432 Longevity & Abrasion Rating (1-5) 33333344444434444444 UV Resistance Rating (1-5) 23533255555522233333 Suction & Delivery Hose 4 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com |||||||||||||||||||||||||||| ||||||||||||||||||||||||||||||||||||||||||||
CDOR CUOR CUORAS CSOR CS CSAS CSF CSS MTH SPH SPHXE CSH AQHL AQH AQHD 13 13 13 13 14 14 14 14 15 15 15 15 16 16 16 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 1/ 2” 1” 1” 1” 1” 1” 4” 4” 2” Metric Metric 5/ 8” 3/ 8” 3/ 8” 3/ 8” 6” 10” 10” 10” 10” 10” 10” 12” 21/ 2” Metric Metric 2” 3” 3” 3” 12.0 25.4 25.4 25.4 25.4 25.4 102.0 102.0 12.0 14.0 14.0 16.0 10.0 10.0 10.0 152.0 254.0 254.0 254.0 254.0 254.0 254.0 304.0 102.0 51.0 51.0 51.6 76.0 76.0 76.0 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 114 113 113 160 160 160 − − − − − 102 25 26 31 333222224244554 344555553333223 333344443333333 Suction & Delivery Hose 5 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com Filter the Griflex website by •Your application •Hose construction •Air / Liquid / Solids •Product Properties Need Help Making a Selection? www.griflex.com
System WF WFUV WFSH SF SFXE SFSH SFOR SFPUL WFB SFBFG SFBOR SFXEBOR CPU CPUAS CPUFR CV CVL CVLFR CVLFRAS VL VHW Page No. 16 17 17 17 17 18 18 18 18 19 19 19 19 20 20 20 20 21 21 21 21 Temp Range oC Min -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -25 -25 -25 -10 -10 -10 -10 -10 -10 Max +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +85 +85 +85 +60 +60 +60 +60 +60 +60 Size Range Inches Min 3/ 8” 3/ 8” 3/ 8” 3/ 8” 3/ 8” 3/ 8” 3/ 8” 3/ 4” 3/ 8” 3/ 8” 1/ 2” 1/ 2” 1” 1” 1” Metric Metric Metric Metric 1” 1” Max 6” 6” 6” 6” 6” 5” 6” 4” 4” 4” 2” 2” 10” 10” 10” 10” 10” 10” 10” 4.5” 4.5” mm Min 10.0 10.0 10.0 10.0 10.0 10.0 10.0 19.0 10.0 10.0 13.0 13.0 25.4 25.4 25.4 20.0 20.0 20.0 20.0 25.0 25.0 Max 152.0 152.0 152.0 152.0 152.0 127.0 152.0 102.0 102.0 102.0 51.0 51.0 254.0 254.0 254.0 254.0 254.0 254.0 254.0 115.0 115.0 Agriculture •••••••••••••••• Automotive • •• •••••••• Construction ••••••••••••••••••• Domestic • • Leisure & Marine •••••••••••• Industrial ••••• •••••••••• • Marine •••••••••••• • • Mining •••••••••• Rail •••••••••••• • • • • Food Grade (EU2011) • • • • • Fire Retardant • • • Anti Static • • Bend Radius mm (Based on 1”) 50 50 50 50 40 50 50 50 60 60 60 48 25 25 25 20 25 25 30 13 16 Flexibility Rating (1-5) 333343332224555555555 Longevity & Abrasion Rating (1-5) 333434455555444322222 UV Resistance Rating (1-5) 353334433344444333323 Wire Reinforced Hose Application Guide Ducting Hose 6 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com |||||||||||||||||||||||||||| ||||||||||||||||||||||||||||||||||||||||||||
MH BCH MHPU XL HN HNHIVIS BPU LAH LAHX GPA CMP ASH ASHL APWH PWH FLU DDH BDDH RFH 22 22 22 22 23 23 23 23 24 24 24 24 25 25 25 25 26 26 26 -10 -10 -25 -10 -10 -10 -25 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 +60 +60 +85 +60 +60 +60 +85 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 +60 1/ 8” 1/ 2” 1/ 5” 1/ 4” 3/ 16” 3/ 16” 1/ 5” 1/ 4” 1/ 5” 3/ 16” 1/ 4” 1/ 4” 1/ 4” 1/ 2” 1/ 2” 1/ 2” 3/ 4” 3/ 4” 3/ 4” 2” 1” 3/ 4” 2” 2” 2” 3/ 4” 3/ 4” 3/ 4”1” 1” 1” 1” 1” 1” 1” 1” 1” 1” 3.0 12.0 5.0 6.3 5.0 5.0 5.0 6.3 5.0 5.0 6.0 6.3 6.3 12.5 12.5 12.5 19.0 19.0 19.0 50.0 25.0 19.0 50.0 50.0 50.0 19.0 19.0 19.0 25.0 25.0 25.0 25.0 25.0 25.0 25.0 25.0 25.0 25.0 ••••••••••••••••••• • • • • • • • • • • • • •••••••• •• • • ••• ••••• ••• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •• •• • •••• • • • • • • • • • • • • • • • • • • • − 200 − 163 162.5 163 − − − 241 180 210 180 125 125 133 170 170 170 4344444444444443444 2252335223333233333 2332233233233333333 Tubing and Braided Hose 7 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com Griflex create hundreds of new product solutions every year; custom-made to the specific needs of the customer. •Advanced material selection •Alternative colour options •Cut lengths •Branded packaging solutions •Corporate branding Need a Bespoke Product Solution? www.griflex.com
Suction and Delivery Hose CD Water Delivery Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, slurries and powders. This product is particularly popular in the agricultural, horticultural, marine and construction industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible PVC cover, with a smooth inside wall. Colour Standard - Transparent Green, Transparent Yellow, Black. Size Range ½” to 8” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CD05 ½” 12.0 10 57 7 0.16 CD06 5⁄ 8” 16.0 9.5 72 7 0.26 CD07 ¾” 19.0 9 86 7 0.28 CDM20 Metric 20.0 8 75 7 0.28 CDM25 Metric 25.0 8 120 7 0.33 CD10 1” 25.4 8 114 7 0.33 CDM28 Metric 28.0 7 130 7 0.38 CDM30 Metric 30.0 7 140 7 0.42 CD12 1¼” 32.0 7 143 7 0.46 CDM35 Metric 35.0 7 160 7 0.50 CD15 1½” 38.0 6.5 171 7 0.55 CDM40 Metric 40.0 6.5 180 7 0.61 CDM45 Metric 45.0 6.5 200 7 0.67 CD20 2” 51.6 6 230 7 0.81 CDM60 Metric 60.0 5 270 7 0.97 CD25 2½” 63.5 5 284 7 1.04 CD30 3” 76.0 4 342 7 1.38 CDM80 Metric 80.0 4 360 7 1.56 CD35 3½” 90.0 4 430 7 1.80 CD40 4” 102.0 4 459 7 2.16 CD50 5” 127.0 3.7 680 7 3.20 CDM140 5½” 140.0 3 730 7 3.77 CD60 6” 152.0 3 810 7 4.22 CD80 8” 203.0 1.5 900 7 8.50 CDXE Water Delivery Super Elastic Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, slurries and powders. This product is particularly popular in the agricultural, horticultural, marine and construction industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible super elastic PVC cover, with a smooth inside wall. Colour Standard - Transparent Green, Transparent Yellow, Black. Size Range ½” to 4” 20mm to 80mm Standard Length 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CDXE05 ½” 12.0 10 50 7 0.17 CDXE06 5⁄ 8” 16.0 9.5 64 7 0.20 CDXE07 ¾” 19.0 9 76 7 0.28 CDXEM20 Metric 20.0 8 75 7 0.30 CDXEM25 Metric 25.0 8 120 7 0.37 CDXE10 1” 25.4 8 102 7 0.39 CDM28 Metric 28.0 7 130 7 0.42 CDXEM30 Metric 30.0 7 140 7 0.45 CDXE12 1¼” 32.0 7 127 7 0.47 CDXEM35 Metric 35.0 7 160 7 0.52 CDXE15 1½” 38.0 6.5 152 7 0.56 CDXEM40 Metric 40.0 6.5 180 7 0.61 CDXEM45 Metric 45.0 6.5 200 7 0.70 CDXE20 2” 51.6 6 204 7 0.82 CDXEM60 Metric 60.0 5 270 7 0.98 CDXE25 2½” 63.5 5 254 7 1.07 CDXE30 3” 76.0 4 304 7 1.36 CDXEM80 Metric 80.0 4 360 7 1.48 CDXE35 3½” 89.0 4 356 7 1.77 CDXE40 4” 102.0 4 406 7 2.13 CDLXE Super Elastic Lightweight Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, slurries and powders. This product is particularly popular in the agricultural, horticultural, marine and construction industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible super elastic PVC cover, with a smooth inside wall. Colour Standard - Transparent Green, Transparent Yellow, Black. Size Range ½” to 2” 20mm to 45mm Standard Length 30/50 metres supplied in a coil. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CDLXE05 ½” 12.0 3.2 57 7 0.11 CDLXE06 5⁄ 8” 16.0 3.2 72 7 0.17 CDLXE07 ¾” 19.0 3 86 7 0.19 CDLXEM20 Metric 20.0 2.9 110 7 0.20 CDLXE10 1” 25.4 2.8 114 7 0.27 CDLXEM28 Metric 28.0 0.27 125 7 0.30 CDLXEM30 Metric 30.0 2.7 136 7 0.33 CDLXE12 1¼” 32.0 2.7 143 7 0.35 CDLXEM35 Metric 35.0 2.5 160 7 0.42 CDLXE15 1½” 38.0 2.3 171 7 0.46 CDLXEM40 Metric 40.0 2.2 185 7 0.48 CDLXEM45 Metric 45.0 2.1 213 7 0.64 CDLXE20 2” 51.6 2 230 7 0.74 CDXT Extreme Elastic, Water Delivery Key features • Tough, extremely flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance • Smooth exterior provides easy routing & greater strength Applications Water, slurries and powders. This product is particularly popular in the agricultural, horticultural, marine and construction industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible PVC cover, with a smooth inside wall. Colour Standard - Transparent Green. Size Range ½” to 4” 20mm to 80mm Standard Length 30m coils. 50m coils also available up to 80mm. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CDXT05 ½” 12.0 10 50 7 0.16 CDXT06 5⁄ 8” 16.0 9.5 60 7 0.20 CDXT07 ¾” 19.0 9 70 7 0.27 CDXTM20 Metric 20.0 8 70 7 0.28 CDXTM25 Metric 25.0 8 110 7 0.32 CDXT10 1” 25.4 8 90 7 0.38 CDXTM28 Metric 28.0 7 120 7 0.41 CDXTM30 Metric 30.0 7 130 7 0.44 CDXT12 1¼” 32.0 7 110 7 0.46 CDXTM35 Metric 35.0 7 140 7 0.50 CDXT15 1½” 38.0 6.5 140 7 0.56 CDXTM40 Metric 40.0 6.5 160 7 0.61 CDXTM45 Metric 45.0 6.5 180 7 0.67 CDXT20 2” 51.6 6 180 7 0.81 CDXTM60 Metric 60.0 5 240 7 0.96 CDXT25 2½” 63.5 5 230 7 1.07 CDXT30 3” 76.0 4 270 7 1.36 CDXTM80 Metric 80.0 4 320 7 1.48 CDXT35 3½” 89.0 4 320 7 1.75 CDXT40 4” 102.0 4 370 7 2.11 REACh MANUFACTURED UK OWNED& Hose & Ducting - Selection Guide Suction and Delivery Hose Wire Reinforced Hose Ducting Hose Tubing and Braided Hose pages 8-16 pages 16-19 pages 19-21 pages 22-26 8 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com
Suction and Delivery Hose ASDH Agricultural Seed Drill Hose Key features • Non-toxic EN10-2011 approved materials • Flexible, tough and durable • Outstanding resistance to the effects of weather • Minimum frictional loss from smooth bore • Excellent chemical resistance Applications Designed & Developed for use with Agricultural Seed Drilling machinery. Available in imperial and metric internal diameter sizes, to suit various machinery specifications. Construction Manufactured from a rigid crush resistant anti-shock PVC Spiral helix encapsulated in a Clear UV resistant flexible PVC with a smooth inner wall. Manufactured from FDA approved ingredients and is non-toxic. Colour Standard - Clear with Black Helix. Size Range ½” to 4” 20mm to 80mm Standard Length 30m & 50m coils. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr ASDH05 ½” 12.0 10 50 7 0.17 ASDH06 5⁄ 8” 16.0 9.5 60 7 0.20 ASDH07 ¾” 19.0 9 70 7 0.28 ASDHM20 Metric 20.0 8 80 7 0.30 ASDHM25 Metric 25.0 8 120 7 0.37 ASDH10 1” 25.4 8 100 7 0.39 ASDHM28 Metric 28.0 7 130 7 0.42 ASDHM30 Metric 30.0 7 140 7 0.45 ASDH12 1¼” 32.0 7 130 7 0.47 ASDHM35 Metric 35.0 7 160 7 0.52 ASDH15 1½” 38.0 6.5 150 7 0.56 ASDHM40 Metric 40.0 6.5 180 7 0.61 ASDHM45 Metric 45.0 6.5 200 7 0.70 ASDH20 2” 51.6 6 210 7 0.82 ASDHM60 Metric 60.0 5 270 7 0.98 ASDH25 2½” 63.5 5 260 7 1.07 ASDH30 3” 76.0 4 310 7 1.36 ASDHM80 Metric 80.0 4 360 7 1.48 ASDH35 3½” 89.0 4 360 7 1.77 ASDH40 4” 102.0 4 410 7 2.13 CDFG Food Grade Delivery Hose Key features • FDA and EU 10-2011 approved compound for food contact. • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, slurries and powders. This product is particularly popular in the agricultural, horticultural, marine and construction industries. Construction Crush resistant anti- shock PVC spiral helix encapsulated in a flexible PVC cover, with a smooth inside wall. Colour Standard - Transparent. Size Range ½” to 8” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CDFG05 ½” 12.0 10 57 7 0.16 CDFG06 5⁄ 8” 16.0 9.5 72 7 0.26 CDFG07 ¾” 19.0 9 86 7 0.28 CDFGM20 Metric 20.0 8 75 7 0.28 CDFGM25 Metric 25.0 8 120 7 0.33 CDFG10 1” 25.4 8 114 7 0.33 CDFGM30 Metric 30.0 7 140 7 0.42 CDFG12 1¼” 32.0 7 143 7 0.46 CDFGM35 Metric 35.0 7 160 7 0.50 CDFG15 1½” 38.0 6.5 171 7 0.55 CDFGM40 Metric 40.0 6.5 180 7 0.61 CDFGM45 Metric 45.0 6.5 200 7 0.67 CDFG20 2” 51.6 6 230 7 0.81 CDFGM60 Metric 60.0 5 270 7 0.97 CDFG25 2½” 63.5 5 284 7 1.04 CDFG30 3” 76.0 4 342 7 1.38 CDFGM80 Metric 80.0 4 360 7 1.56 CDFG35 3½” 90.0 4 430 7 1.80 CDFG40 4” 102.0 4 459 7 2.16 CDFG50 5” 127.0 3.7 680 7 3.20 CDFGM140 5½” 140.0 3 730 7 3.77 CDFG60 6” 152.0 3 810 7 4.22 CDFG80 8” 203.0 1.5 900 7 8.50 ASDHXE Agricultural Seed Drill Hose Super Elastic Key features • Non-toxic EN10-2011 approved materials • SuperFlexible, tough and durable • Outstanding resistance to the effects of weather • Minimum frictional loss from smooth bore • Excellent chemical resistance Applications Designed & Developed for use with Agricultural Seed Drilling machinery. Available in imperial and metric internal diameter sizes, to suit various machinery specifications. Construction Manufactured from a rigid crush resistant anti-shock PVC Spiral helix encapsulated in a Clear UV resistant super flexible PVC with a smooth inner wall. Manufactured from FDA approved ingredients and is non-toxic. Colour Standard - Clear with Black Helix. Size Range ½” to 4” 20mm to 80mm Standard Length 30m & 50m coils. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr ASDHXE05 ½” 12.0 10 50 7 0.17 ASDHXE06 5⁄ 8” 16.0 9.5 50 7 0.20 ASDHXE07 ¾” 19.0 9 60 7 0.28 ASDHXEM20 Metric 20.0 8 70 7 0.30 ASDHXEM25 Metric 25.0 8 110 7 0.37 ASDHXE10 1” 25.4 8 90 7 0.39 ASDHXEM28 Metric 28.0 7 120 7 0.42 ASDHXEM30 Metric 30.0 7 130 7 0.45 ASDHXE12 1¼” 32.0 7 120 7 0.47 ASDHXEM35 Metric 35.0 7 140 7 0.52 ASDHXE15 1½” 38.0 6.5 140 7 0.56 ASDHXEM40 Metric 40.0 6.5 160 7 0.61 ASDHXEM45 Metric 45.0 6.5 180 7 0.70 ASDHXE20 2” 51.6 6 190 7 0.82 ASDHXEM60 Metric 60.0 5 240 7 0.98 ASDHXE25 2½” 63.5 5 230 7 1.07 ASDHXE30 3” 76.0 4 280 7 1.36 ASDHXEM80 Metric 80.0 4 320 7 1.48 ASDHXE35 3½” 89.0 4 320 7 1.77 ASDHXE40 4” 102.0 4 370 7 2.13 CDAS Anti-static Delivery Hose Key features • FDA and EU 10-2011 approved compound for food contact • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, slurries and powders. This product is particularly popular in the agricultural, horticultural, marine and construction industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible PVC cover, with a smooth inside wall. Colour Standard - Transparent. Size Range ½” to 8” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CDAS05 ½” 12.0 10 57 7 0.16 CDAS06 5⁄ 8” 16.0 9.5 72 7 0.26 CDAS07 ¾” 19.0 9 86 7 0.28 CDASM20 Metric 20.0 8 75 7 0.28 CDASM25 Metric 25.0 8 120 7 0.33 CDAS10 1” 25.4 8 114 7 0.33 CDASM30 Metric 30.0 7 140 7 0.42 CDAS12 1¼” 32.0 7 143 7 0.46 CDASM35 Metric 35.0 7 160 7 0.50 CDAS15 1½” 38.0 6.5 171 7 0.55 CDASM40 Metric 40.0 6.5 180 7 0.61 CDASM45 Metric 45.0 6.5 200 7 0.67 CDAS20 2” 51.6 6 230 7 0.81 CDASM60 Metric 60.0 5 270 7 0.97 CDAS25 2½” 63.5 5 284 7 1.04 CDAS30 3” 76.0 4 342 7 1.38 CDASM80 Metric 80.0 4 360 7 1.56 CDAS35 3½” 90.0 4 430 7 1.80 CDAS40 4” 102.0 4 459 7 2.16 CDAS50 5” 127.0 3.7 680 7 3.20 CDASM140 5½” 140.0 3 730 7 3.77 CDAS60 6” 152.0 3 810 7 4.22 CDAS80 8” 203.0 1.5 900 7 8.50 9 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com
Suction and Delivery Hose SDSXE Seed Drill Smooth Super Elastic Key features • Tough, super flexible and durable • Non-toxic EN10-2011 approved materials • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance • Smooth outer Applications Designed & developed for use with Agricultural Seed Drilling machinery. Available in imperial and metric internal diameter sizes, to suit various machinery specifications. Construction Manufactured from a rigid crush resistant anti-shock PVC Spiral helix encapsulated in a Clear UV resistant flexible PVC smooth cover together with a smooth inner and outer wall. Manufactured from FDA approved ingredients and is non-toxic. Colour Standard - Clear with Black Helix. Size Range ½” to 4” 20mm to 80mm Standard Length 30/50 metres supplied in a coil. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm WEIGHT Kg/Mtr SDSXE05 ½” 12.0 10 50 0.17 SDSXE06 5⁄ 8” 16.0 9.5 64 0.20 SDSXE07 ¾” 19.0 9 76 0.28 SDSXEM20 Metric 20.0 8 75 0.30 SDSXEM25 Metric 25.0 8 120 0.37 SDSXE10 1” 25.4 8 102 0.39 SDSXEM28 Metric 28.0 7 130 0.42 SDSXEM30 Metric 30.0 7 140 0.45 SDSXE12 1¼” 32.0 7 127 0.47 SDSXEM35 Metric 35.0 7 160 0.52 SDSXE15 1½” 38.0 6.5 152 0.56 SDSXEM40 Metric 40.0 6.5 180 0.61 SDSXEM45 Metric 45.0 6.5 200 0.70 SDSXE20 2” 51.6 6 204 0.82 SDSXEM60 Metric 60.0 5 270 0.98 SDSXE25 2½” 63.5 5 254 1.07 SDSXE30 3” 76.0 4 304 1.36 SDSXEM80 Metric 80.0 4 360 1.48 SDSXE35 3½” 89.0 4 356 1.77 SDSXE40 4” 102.0 4 406 2.13 SDSXT Seed Drill Smooth Extreme Elastic Key features • Non-toxic EN10-2011 approved materials • Extremely Flexible, tough and durable • Outstanding resistance to the effects of weather • Smooth inner and outer for minimal friction • Excellent chemical resistance Applications Designed & Developed for use with Agricultural Seed Drilling machinery. Available in imperial and metric internal diameter sizes, to suit various machinery specifications. Construction Manufactured from a rigid crush resistant anti-shock PVC Spiral helix encapsulated in a Clear UV resistant extremely flexible PVC smooth cover together with a smooth inner wall. Manufactured from FDA approved ingredients and is non-toxic. Colour Standard - Clear with Black Helix. Size Range ½” to 4” 20mm to 80mm Standard Length 30m & 50m coils. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm WEIGHT Kg/Mtr SDSXT05 ½” 12.0 10 50 0.17 SDSXT06 5⁄ 8” 16.0 9.5 60 0.20 SDSXT07 ¾” 19.0 9 70 0.28 SDSXTM20 Metric 20.0 8 70 0.30 SDSXTM25 Metric 25.0 8 110 0.37 SDSXT10 1” 25.4 8 90 0.39 SDSXTM28 Metric 28.0 7 120 0.42 SDSXTM30 Metric 30.0 7 130 0.45 SDSXT12 1¼” 32.0 7 120 0.47 SDSXTM35 Metric 35.0 7 150 0.52 SDSXT15 1½” 38.0 6.5 140 0.56 SDSXTM40 Metric 40.0 6.5 160 0.61 SDSXTM45 Metric 45.0 6.5 180 0.70 SDSXT20 2” 51.6 6 190 0.82 SDSXTM60 Metric 60.0 5 250 0.98 SDSXT25 2½” 63.5 5 230 1.07 SDSXT30 3” 76.0 4 280 1.36 SDSXTM80 Metric 80.0 4 330 1.48 SDSXT35 3½” 89.0 4 320 1.77 SDSXT40 4” 102.0 4 370 2.13 PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm WEIGHT Kg/Mtr ASDHXT05 ½” 12.0 10 40 0.17 ASDHXT06 5⁄ 8” 16.0 9.5 50 0.20 ASDHXT07 ¾” 19.0 9 60 0.28 ASDHXTM20 Metric 20.0 8 60 0.30 ASDHXTM25 Metric 25.0 8 100 0.37 ASDHXT10 1” 25.4 8 80 0.39 ASDHXTM28 Metric 28.0 7 100 0.42 ASDHXTM30 Metric 30.0 7 110 0.45 ASDHXT12 1¼” 32.0 7 100 0.47 ASDHXTM35 Metric 35.0 7 130 0.52 ASDHXT15 1½” 38.0 6.5 120 0.56 ASDHXTM40 Metric 40.0 6.5 140 0.61 ASDHXTM45 Metric 45.0 6.5 160 0.70 ASDHXT20 2” 51.6 6 170 0.82 ASDHXTM60 Metric 60.0 5 220 0.98 ASDHXT25 2½” 63.5 5 210 1.07 ASDHXT30 3” 76.0 4 250 1.36 ASDHXTM80 Metric 80.0 4 290 1.48 ASDHXT35 3½” 89.0 4 290 1.77 ASDHXT40 4” 102.0 4 330 2.13 ASDHXT Agricultural Seed Drill Hose Extreme Elastic Key features • Non-toxic EN10-2011 approved materials • Extremely Flexible, tough and durable • Outstanding resistance to the effects of weather • Minimum frictional loss from smooth bore • Excellent chemical resistance Applications Designed & Developed for use with Agricultural Seed Drilling machinery. Available in imperial and metric internal diameter sizes, to suit various machinery specifications. Construction Manufactured from a rigid crush resistant anti-shock PVC Spiral helix encapsulated in a Clear UV resistant extremely flexible PVC with a smooth inner wall. Manufactured from FDA approved ingredients and is non-toxic. Colour Standard - Clear with Black Helix. Size Range ½” to 4” 20mm to 80mm Standard Length 30m & 50m coils. Temperature Range -10°C to +60°C SDS Seed Drill Smooth Key features • Non-toxic EN10-2011 approved materials • Flexible, tough and durable • Outstanding resistance to the effects of weather • Smooth inner and outer for minimal friction • Excellent chemical resistance Applications Designed & Developed for use with Agricultural Seed Drilling machinery. Available in imperial and metric internal diameter sizes, to suit various machinery specifications. Construction Manufactured from a rigid crush resistant anti-shock PVC Spiral helix encapsulated in a Clear UV resistant flexible PVC smooth cover together with a smooth inner wall. Manufactured from FDA approved ingredients and is non-toxic. Colour Standard - Clear with Black Helix. Size Range ½” to 4” 20mm to 80mm Standard Length 30m & 50m coils. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm WEIGHT Kg/Mtr SDS05 ½” 12.0 10 60 0.17 SDS06 5⁄ 8” 16.0 9.5 70 0.20 SDS07 ¾” 19.0 9 90 0.28 SDSM20 Metric 20.0 8 90 0.30 SDSM25 Metric 25.0 8 130 0.37 SDS10 1” 25.4 8 110 0.39 SDSM28 Metric 28.0 7 150 0.42 SDSM30 Metric 30.0 7 160 0.45 SDS12 1¼” 32.0 7 140 0.47 SDSM35 Metric 35.0 7 180 0.52 SDS15 1½” 38.0 6.5 170 0.56 SDSM40 Metric 40.0 6.5 200 0.61 SDSM45 Metric 45.0 6.5 220 0.70 SDS20 2” 51.6 6 230 0.82 SDSM60 Metric 60.0 5 300 0.98 SDS25 2½” 63.5 5 280 1.07 SDS30 3” 76.0 4 340 1.36 SDSM80 Metric 80.0 4 400 1.48 SDS35 3½” 89.0 4 390 1.77 SDS40 4” 102.0 4 450 2.13 10 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com
CU Medium Duty Premium Key features • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Construction Rigid crush resistant anti-shock PVC spiral helix encapsulated in an olive green flexible PVC cover, with a smooth inside wall. Colour Standard - Olive Green. Size Range 1” to 10” 28mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CU10 1” 25.4 9.3 113 9 0.49 CUM28 Metric 28.0 8.4 120 9 0.54 CUM30 Metric 30.0 8.2 130 9 0.56 CU12 1¼” 32.0 8 144 9 0.58 CUM35 Metric 35.0 8 160 9 0.62 CU15 1½” 38.0 8 171 9 0.68 CUM40 Metric 40.0 7.3 200 9 0.75 CUM45 Metric 45.0 7.3 215 9 0.90 CU20 2” 51.6 7.3 230 9 1.04 CUM60 Metric 60.0 6.7 260 9 1.26 CU25 2½” 63.5 6.7 284 9 1.36 CU30 3” 76.0 6 342 9 1.70 CUM80 Metric 80.0 5 360 9 1.75 CU35 3½” 90.0 5 401 9 2.06 CU40 4” 102.0 4.7 459 9 2.62 CU50 5” 127.0 4 572 8 3.49 CUM140 5½” 140.0 3.3 646 8 4.08 CU60 6” 152.0 3.3 684 8 4.43 CU80 8” 204.0 2.7 914 8 7.76 CU100 10” 254.0 2 1143 8 11.60 CUL Medium Duty Standard Key features • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in an olive green flexible PVC cover, with a smooth inside wall. Colour Standard - Green. Size Range 1” to 8” 28mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUL10 1” 25.4 8 100 8 0.36 CULM28 Metric 28.0 7 110 8 0.41 CULM30 Metric 30.0 7 120 8 0.43 CUL12 1¼” 32.0 7 130 8 0.46 CULM35 Metric 35.0 6 140 8 0.52 CUL15 1½” 38.0 6.3 140 8 0.57 CULM40 Metric 40.0 5.5 180 8 0.62 CULM45 Metric 45.0 5.5 190 8 0.70 CUL20 2” 51.6 5.3 200 8 0.83 CULM60 Metric 60.0 5 230 8 0.97 CUL25 2½” 63.5 5 250 8 1.05 CUL30 3” 76.0 4 300 8 1.47 CULM80 Metric 80.0 4 320 8 1.60 CUL35 3½” 90.0 4 360 8 2.13 CUL40 4” 102.0 4 400 8 2.17 CUL50 5” 127.0 3.7 500 8 3.20 CULM140 5½” 140.0 3 565 6 3.80 CUL60 6” 152.0 3 600 6 4.22 CUL80 8” 203.0 1.5 800 6 8.50 Suction and Delivery Hose CUXE Super Elastic Medium Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a sea green super elastic flexible PVC cover, with a smooth inside wall. Colour Standard - Sea Green. Size Range 1” to 10” 28mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUXE10 1” 25.4 9.3 113 9 0.49 CUXEM28 Metric 28.0 8.5 128 9 0.53 CUXEM30 Metric 30.0 8 130 9 0.56 CUXE12 1¼” 32.0 8 144 9 0.58 CUXEM35 Metric 35.0 8 162 9 0.64 CUXE15 1½” 38.0 8 171 9 0.68 CUXEM40 Metric 40.0 7.8 185 9 0.74 CUXEM45 Metric 45.0 7.5 204 9 0.90 CUXE20 2” 51.6 7.3 230 9 1.04 CUXEM60 Metric 60.0 6.9 270 9 1.25 CUXE25 2½” 63.5 6.7 284 9 1.36 CUXE30 3” 76.0 6 342 9 1.70 CUXEM80 Metric 80.0 5.5 385 9 1.85 CUXE35 3½” 90.0 5 401 9 2.06 CUXE40 4” 102.0 4.7 459 9 2.62 CUXE50 5” 127.0 4 572 8 3.49 CUXEM140 5½” 140.0 3.4 646 8 4.03 CUXE60 6” 152.0 3.3 684 8 4.43 CUXE80 8” 204.0 2.7 914 8 7.76 CUXE100 10” 254.0 2 1143 8 11.60 CUXES External Scuff Strip Key features • Excellent abrasion resistance from external scuff strip • Higher working pressures due to thick wall • Minimal drag resistance • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Compounded for low temperature flexibility • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Widely used in agricultural tanker applications. Construction Elastic quality flexible PVC with a crush resistant anti-shock PVC spiral helix, an abrasion resistant PVC scuff strip and a smooth inside wall. Colour Standard - Grey, Green Scuff Strip. Size Range 1” to 10” 28mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUXES10 1” 25.4 9.3 113 9 0.5 CUXESM28 Metric 28.0 8.5 128 9 5.3 CUXESM30 Metric 30.0 8 130 9 5.7 CUXES12 1¼” 32.0 8 144 9 0.58 CUXESM35 Metric 35.0 8 162 9 0.64 CUXES15 1½” 38.0 8 171 9 0.7 CUXESM40 Metric 40.0 7.8 185 9 0.74 CUXESM45 Metric 45.0 7.5 204 9 0.9 CUXES20 2” 51.6 7.3 230 9 1.05 CUXESM60 Metric 60.0 6.9 270 9 1.25 CUXES25 2½” 63.5 6.7 284 9 1.39 CUXES30 3” 76.0 6 342 9 1.7 CUXESM80 Metric 80.0 5.5 385 9 1.85 CUXES35 3½” 90.0 5 401 9 2.25 CUXES40 4” 102.0 4.7 459 9 2.7 CUXES50 5” 127.0 4 572 8 3.9 CUXESM140 5½” 140.0 3.4 646 8 4.55 CUXES60 6” 152.0 3.3 684 8 5 CUXES80 8” 204.0 2.7 914 8 9.5 CUXES100 10” 254.0 2 1143 8 13.5 11 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com
Suction and Delivery Hose PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUAS10 1” 25.4 9.3 110 9 0.49 CUASM28 Metric 28.0 8.4 120 9 0.54 CUASM30 Metric 30.0 8.2 130 9 0.56 CUAS12 1¼” 32.0 8.0 140 9 0.58 CUASM35 Metric 35.0 8.0 160 9 0.62 CUAS15 1½” 38.0 8.0 170 9 0.68 CUASM40 Metric 40.0 7.3 200 9 0.75 CUASM45 Metric 45.0 7.3 220 9 0.88 CUAS20 2” 51.6 7.3 230 9 1.04 CUASM60 Metric 60.0 6.7 260 9 1.26 CUAS25 2½” 63.0 6.7 280 9 1.36 CUAS30 3” 76.0 6.0 340 9 1.70 CUASM80 Metric 80.0 5.0 360 9 1.82 CUAS35 3½” 90.0 5.0 400 9 2.06 CUAS40 4” 102.0 4.7 460 9 2.62 CUAS50 5” 127.0 4.0 570 8 3.49 CUASM140 5½” 140.0 3.3 650 8 4.08 CUAS60 6” 152.0 3.3 680 8 4.43 CUAS80 8” 204.0 2.7 910 8 10.45 CUAS100 10” 254.0 2.0 1140 8 11.60 CUAS Premium Medium Duty Anti-Static Key features • Stranded copper wire for static discharge • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Construction Rigid crush resistant anti-shock PVC spiral helix and antistatic copper strands encapsulated in a flexible PVC cover, with a smooth inside wall. Colour Standard - Olive Green. Size Range 1” to 8” 28mm to 140mm Standard Length 30m Coils up to 6”. 50m Coils also available up to 80mm. 10m Straight cured lengths over 6”. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUXS10 1” 25.4 6.7 100 9 0.50 CUXS12 1¼” 32.0 5.7 128 9 0.60 CUXS15 1½” 38.0 5.3 152 9 0.70 CUXSM40 Metric 40.0 3.5 140 9 0.74 CUXSM45 Metric 45.0 3.5 155 9 0.90 CUXS20 2” 51.6 5 204 9 1.05 CUXSM60 Metric 60.0 3 210 9 1.25 CUXS25 2½” 63.5 4.7 252 9 1.39 CUXS30 3” 76.0 4.3 304 9 1.70 CUXSM80 Metric 80.0 2 280 9 1.85 CUXS35 3½” 90.0 2 315 9 2.25 CUXS40 4” 102.0 4 408 9 2.70 CUXS50 5” 127.0 3.3 508 8 3.90 CUXSM140 5½” 140.0 1.5 490 8 4.55 CUXS60 6” 152.0 3.3 608 8 5.00 CUXS80 8” 204.0 1.5 812 8 10.00 CUXS100 10” 254.0 1.3 1016 8 14.00 CUXS External Spiral Elastic Key features • Excellent abrasion resistance from external scuff strip • Higher working pressures due to thick wall • Minimal drag resistance • Tough, flexible and extremely durable • Outstanding resistance to the effects of weather • Compounded for low temperature flexibility • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Widely used in agricultural tanker applications. Construction Elastic quality flexible PVC with a crush resistant anti-shock PVC spiral helix, an abrasion resistant PVC scuff strip and a smooth inside wall. Colour Standard - Grey, Green Scuff Strip. Size Range 1” to 10” 28mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUXESZ10 1” 25.4 3.72 84 9 0.49 CUXESZM28 Metric 28.0 3.4 95 9 0.53 CUXESZM30 Metric 30.0 3.2 96 9 0.56 CUXESZ12 1¼” 32.0 3.2 107 9 0.58 CUXESZM35 Metric 35.0 3.2 120 9 0.64 CUXESZ15 1½” 38.0 3.2 127 9 0.68 CUXESZM40 Metric 40.0 3.1 137 9 0.74 CUXESZM45 Metric 45.0 3 151 9 0.90 CUXESZ20 2” 51.6 3 170 9 1.04 CUXESZM60 Metric 60.0 3 200 9 1.25 CUXESZ25 2½” 63.5 3 210 9 1.36 CUXESZ30 3” 76.0 3 253 9 1.70 CUXESZM80 Metric 80.0 3 285 9 1.85 CUXESZ35 3½” 90.0 2.5 297 9 2.06 CUXESZ40 4” 102.0 2 340 9 2.62 CUXESZ Sub Zero Super Elastic Key features • Tough, durable and extremely flexible down to -40°C • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. This product is particularly popular in the agricultural, construction & general manufacturing industries. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a blue low temperature super elastic flexible PVC cover, with a smooth inside wall. Colour Standard - Blue. Size Range 1” to 4” 28mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -40°C to +60°C 12 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUS20 2” 51.6 5 220 9 0.85 CUS25 2½” 63.5 4 250 9 1.15 CUS30 3” 76.0 4 330 9 1.45 CUS35 3½” 90.0 4 400 9 2.00 CUS40 4” 102.0 3 430 9 2.20 CUS50 5” 127.0 2.5 550 9 3.20 CUS60 6” 152.0 2 700 9 4.30 CUS Maximum Strength, High Vacuum Hose Key features • High volume delivery hoses • Extra compression strength helps to avoid crushing • Allows continuious use at high vacuum ratings • Minimal frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Suction tankers, agricultural slurry movement, cleaning sewage drains & cesspits. Construction Rigid crush resistant & anti-shock spiral helix with rectangular profile, encapsulated in flexible PVC cover. Colour Grey with orange strip Size Range 2” to 6” Standard Length Straight cured Temperature Range -10°C to +60°C NEW
CDOR Oil Resistant Standard Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical and oil resistance Applications Fuel oils up to a 40% aromatic content including oil, diesel, kerosene, white spirit & mineral based hydraulic oils. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible oil resistant PVC nitrile cover, with a smooth inside wall. Colour Standard - Blue. Size Range ½” to 8” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CDOR05 ½” 12.0 10 57 7 0.16 CDOR06 5⁄ 8 ” 16.0 9.5 72 7 0.26 CDOR07 ¾” 19.0 9 86 7 0.28 CDORM20 Metric 20.0 8 75 7 0.28 CDORM25 Metric 25.0 8 120 7 0.34 CDOR10 1” 25.4 8 114 7 0.34 CDORM28 Metric 28.0 7 130 7 0.39 CDORM30 Metric 30.0 7 140 7 0.43 CDOR12 1¼” 32.0 7 143 7 0.47 CDORM35 Metric 35.0 7 160 7 0.51 CDOR15 1½” 38.0 6.5 171 7 0.56 CDORM40 Metric 40.0 6.5 180 7 0.62 CDORM45 Metric 45.0 6.5 200 7 0.68 CDOR20 2” 51.6 6 230 7 0.82 CDORM60 Metric 60.0 5 270 7 0.99 CDOR25 2½” 63.5 5 284 7 1.06 CDOR30 3” 76.0 4 342 7 1.40 CDORM80 Metric 80.0 4 360 7 1.59 CDOR35 3½” 90.0 4 430 7 1.83 CDOR40 4” 102.0 4 459 7 2.20 CDOR50 5” 127.0 3.7 680 7 3.25 CDORM140 5½” 140.0 3 730 7 3.83 CDOR60 6” 152.0 3 810 7 4.29 CDOR80 8" 203.0 1.5 900 7 8.64 CUOR Oil Resistant Medium Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical and oil resistance Applications Fuel oils up to a 40% aromatic content including oil, diesel, kerosene, white spirit & mineral based hydraulic oils. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible oil resistant PVC nitrile cover, with a smooth inside wall. Colour Standard - Blue. Size Range 1” to 10” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUOR10 1” 25.4 9.3 113 9 0.49 CUORM28 Metric 28.0 8.5 128 9 0.53 CUORM30 Metric 30.0 8 130 9 0.56 CUOR12 1¼” 32.0 8 144 9 0.58 CUORM35 Metric 35.0 8 162 9 0.64 CUOR15 1½” 38.0 8 171 9 0.68 CUORM40 Metric 40.0 7.8 185 9 0.74 CUORM45 Metric 45.0 7.5 204 9 0.90 CUOR20 2” 51.6 7.3 230 9 1.04 CUORM60 Metric 60.0 6.9 270 9 1.25 CUOR25 2½” 63.5 6.7 284 9 1.36 CUOR30 3” 76.0 6 342 9 1.70 CUORM80 Metric 80.0 5.5 385 9 1.85 CUOR35 3½” 90.0 5 401 9 2.06 CUOR40 4” 102.0 4.7 459 9 2.62 CUOR50 5” 127.0 4 572 8 3.49 CUORM140 Metric 140.0 3.4 646 8 4.03 CUOR60 6” 152.0 3.3 684 8 4.43 CUOR80 8” 204.0 2.7 914 8 7.76 CUOR100 10” 254.0 2 1143 8 11.60 CUORAS Oil Resistant Anti-Static Key features • Stranded copper wire for static discharge • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical and oil resistance Applications Fuel oils up to a 40% aromatic content including oil, diesel, kerosene, white spirit & mineral based hydraulic oils. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible oil resistant PVC nitrile cover, with a smooth inside wall. Colour Standard - Blue. Size Range 1” to 10” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CUORAS10 1” 25.4 9.3 113 9 0.49 CUORASM28 Metric 28.0 8.5 128 9 0.53 CUORASM30 Metric 30.0 8 130 9 0.56 CUORAS12 1¼” 32.0 8 144 9 0.58 CUORASM35 Metric 35.0 8 162 9 0.64 CUORAS15 1½” 38.0 8 171 9 0.68 CUORASM40 Metric 40.0 7.8 185 9 0.74 CUORASM45 Metric 45.0 7.5 204 9 0.90 CUORAS20 2” 51.6 7.3 230 9 1.04 CUORASM60 Metric 60.0 6.9 270 9 1.25 CUORAS25 2½” 63.5 6.7 284 9 1.36 CUORAS30 3” 76.0 6 342 9 1.70 CUORASM80 Metric 80.0 5.5 385 9 1.85 CUORAS35 3½” 90.0 5 401 9 2.06 CUORAS40 4” 102.0 4.7 459 9 2.62 CUORAS50 5” 127.0 4 572 8 3.49 CUORASM140 Metric 140.0 3.4 646 8 4.03 CUORAS60 6” 152.0 3.3 684 8 4.43 CUORAS80 8” 204.0 2.7 914 8 7.76 CUORAS100 10” 254.0 2 1143 8 11.60 Suction and Delivery Hose 13 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com CSOR Oil Resistant Heavy Duty Key features • Tough, super flexible and durable • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical and oil resistance Applications Fuel oils up to a 40% aromatic content including oil, diesel, kerosene, white spirit & mineral based hydraulic oils. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a flexible oil resistant PVC nitrile cover, with a smooth inside wall. Colour Standard - Blue. Size Range 1” to 10” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CSOR10 1” 25.4 13.3 160 9 0.54 CSORM28 Metric 28 11.5 180 9 0.62 CSORM30 Metric 30 10.1 190 9 0.66 CSOR12 1¼” 32 10.0 200 9 0.68 CSORM35 Metric 35 8.8 220 9 0.78 CSOR15 1½” 38 8.7 230 9 0.9 CSORM40 Metric 40 7.9 260 9 0.98 CSORM45 Metric 45 7.5 280 9 1.17 CSOR20 2” 51.6 7.3 300 9 1.3 CSORM60 Metric 60 5.8 380 9 1.47 CSOR25 2½” 63.5 6.0 370 9 1.6 CSOR30 3” 76 5.7 450 9 1.96 CSORM80 Metric 80 4.8 530 9 2.23 CSOR35 3½” 90 5.0 550 9 2.26 CSOR40 4” 102 4.3 630 9 3.64 CSOR50 5” 127 4.0 850 8 4.83 CSORM140 5½” 140 3.7 1000 8 6.06 CSOR60 6” 152 3.7 1100 8 6.83 CSOR80 8” 204 3.3 2030 8 10.3 CSOR100 10” 254 3.0 2540 8 15.23
Suction and Delivery Hose PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CSAS10 1” 25.4 13.3 160 9 0.53 CSASM28 Metric 28 11.5 180 9 0.61 CSASM30 Metric 30 10.1 190 9 0.65 CSAS12 1¼” 32 10.0 200 9 0.67 CSASM35 Metric 35 8.8 220 9 0.77 CSAS15 1½” 38 8.7 230 9 0.89 CSASM40 Metric 40 7.9 260 9 0.96 CSASM45 Metric 45 7.5 280 9 1.15 CSAS20 2” 51.6 7.3 300 9 1.28 CSASM60 Metric 60 5.8 380 9 1.45 CSAS25 2½” 63.5 6.0 370 9 1.58 CSAS30 3” 76 5.7 450 9 1.93 CSASM80 Metric 80 4.8 530 9 2.2 CSAS35 3½” 90 5.0 550 9 2.23 CSAS40 4” 102 4.3 630 9 3.58 CSAS50 5” 127 4.0 850 8 4.76 CSASM140 5½” 140 3.7 1000 8 5.97 CSAS60 6” 152 3.7 1100 8 6.72 CSAS80 8” 204 3.3 2030 8 10.14 CSAS100 10” 254 3.0 2540 8 15 CSAS Heavy Duty Anti-Static Key features • Stranded copper wire for static discharge • Tough, flexible and extremely durable for severe working conditions • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. Ideal for general industrial applications. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a grey flexible PVC cover, with a smooth inside wall. Colour Standard - Grey. Option - Dark Green. Size Range 1” to 10” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CSS40 4” 102 4.3 630 9 3.95 CSS50 5” 127 4.0 850 9 5.25 CSS60 6” 152 3.7 1100 9 7.45 CSS80 8” 204 3.3 2030 9 11.75 CSS100 10” 254 3.0 2540 9 16.6 CSS120 12” 304 1.5 3000 9 19.5 CSS Heavy Duty Scuff Strip Key features • Excellent abrasion resistance from external scuff strip • Tough, flexible and extremely durable for severe working conditions • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Designed specifically for the fish farming industry. Also suitable for water, sewage, slurries, general industry and powders. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a clear flexible PVC cover, with a smooth inside wall and an external Blue scuff strip. Colour Standard - Clear with Blue scuff strip. Size Range 4” to 12” Standard Length 4” & 5” 30mtr coils. 6” & 8” 20 mtr coils. 10” & 12” 10mtr straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CSF40 4” 102 4.3 630 9 3.58 CSF50 5” 127 4.0 850 8 4.76 CSF60 6” 152 3.7 1100 8 6.72 CSF80 8” 204 3.3 2030 8 10.14 CSF100 10” 254 3.0 2540 8 15 CSF Heavy Duty Fish Hose Key features • Tough, flexible and extremely durable for severe working conditions • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Designed specifically for the fish farming industry. Also suitable for water, sewage, slurries, general industry and powders. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a clear flexible PVC cover, with a smooth inside wall. Colour Standard - Clear. Size Range 4” to 10” Standard Length Up to 6”, 30 metres supplied in a coil. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C 14 T +44 (0)1675 464803 E sales@griflex.com www.griflex.com CS Heavy Duty Key features • Tough, flexible and extremely durable for severe working conditions • Outstanding resistance to the effects of weather • Minimum frictional loss is achieved by the smooth bore • Excellent chemical resistance Applications Water, sewage, slurries and powders. Ideal for general industrial applications. Heavy duty suction hose is supplied in straight lengths with polished aluminum alloy couplings for fire brigade applications. Construction Crush resistant anti-shock PVC spiral helix encapsulated in a grey flexible PVC cover, with a smooth inside wall. Colour Standard - Grey. Option - Dark Green. Size Range 1” to 10” 20mm to 80mm Standard Length Up to 6”, 30 metres supplied in a coil. Up to 80mm, 50 metres coils also available. Over 6”, 10 metres supplied in a straight cured lengths. Temperature Range -10°C to +60°C PRODUCT REF. INTERNAL DIA inch INTERNAL DIA mm WORKING PRESSURE BAR MIN BENDING RADIUS mm Vacuum m of H2O WEIGHT Kg/Mtr CS10 1” 25.4 13.3 160 9 0.53 CSM28 Metric 28 11.5 180 9 0.61 CSM30 Metric 30 10.1 190 9 0.65 CS12 1¼” 32 10.0 200 9 0.67 CSM35 Metric 35 8.8 220 9 0.77 CS15 1½” 38 8.7 230 9 0.89 CSM40 Metric 40 7.9 260 9 0.96 CSM45 Metric 45 7.5 280 9 1.15 CS20 2” 51.6 7.3 300 9 1.28 CSM60 Metric 60 5.8 380 9 1.45 CS25 2½” 63.5 6.0 370 9 1.58 CS30 3” 76 5.7 450 9 1.93 CSM80 Metric 80 4.8 530 9 2.2 CS35 3½” 90 5.0 550 9 2.23 CS40 4” 102 4.3 630 9 3.58 CS50 5” 127 4.0 850 8 4.76 CSM140 5½” 140 3.7 1000 8 5.97 CS60 6” 152 3.7 1100 8 6.72 CS80 8” 204 3.3 2030 8 10.14 CS100 10” 254 3.0 2540 8 15
